Dosing & High Pressure Pump

We are Manufacturing Dosing Pump & High Pressure Triplex Plunger Pump.


High Pressure Triplex Plunger Pumps

We offer High Pressure Triplex Plunger Pump as per req. of Flow Rate & Pressure for many applications such as Washing, Sewage Cleaning, Water Jetting, Hydro Blasting, Reverse Osmosis Process, Etc....
These Pumps are design with pre set packing & concentric ceramic plungers to provise high pressure up to 1000 Kg/ Cm2.


Features :
Extra Heavy duty Power Frame ensures uninterrupted smooth long life.
A three piece liquid end block design avoids any possibility of block cracking.
Spring loaded plunger packing always ensures leak free pumping services.
Easy to maintain, simple to repair & nominal maintenance needed in case of breakdown.

Accessories:-
Safety Relief Valve
Unloading Valve
Pressure Regulating Valve
Trigger Gun/ Handle Bar
High Pressure Hose
Nozzle for Spray


Doising Pump


We are Manufacturing Diaphragm type dosing pumps, which generally working with PTEE Diaphragm between Hydraulic oil and the metered fluid. This type of Dosing pumps is glandless and helps to avoid leakages of toxic, corrosive and costly chemicals or fluids.

We offer dosing pump with captive range of 0 to10000 LPH and Pressure Up to 400 Kg / cm². Our range is available in simplex, duplex or multiple heads for handling various chemicals with a common motor to facilitate the whole operation, as per client requirement.







Features :
Easily handles corrosive, abrasive or viscous fluids.
Steady state metering accuracy of +/-1% of pump output, at single setting of stroke from 10% to 100%. (turn down ration 10:1).
Repeatability better than +/-2.5% of set point.
Flow metering accuracy is almost independent of back pressure of liquid.
Discharge flow rate is linear to variation of stroke length.
Automatic air bleeding from the hydraulic oil to ensure better metering accuracy.
Arrangement of in-built pressure relief valve to protect the pump from pressure exceeding the rated pressure.
Diaphragm is always balanced between the pressures exerted by the hydraulic oil and the liquid to be dosed.

MOC :-
SS 316,  316 L, SS 304, ALLOY STEEL, PP, UHMW, PTFE( Teflon).

Model No. PD - 10
PLUNGER DIA. (MM)
Capacity -- LPH
DISCHARGE PRESSURE
97 SPM
194 SPM
5
1
2
400
11
5
10
320
20
16
32
100
25
25
50
64
35
50
100
32
45
83
166
40

Model No. PD - 20
PLUNGER DIA. (MM)
Capacity -- LPH
DISCHARGE PRESSURE
97 SPM
194 SPM
20
32
64
57
25
51
102
35
35
100
200
18
50
205
410
9
61
306
612
6
70
403
806
4.5
73
438
876
4

Model No. PD - 30
PLUNGER DIA. (MM)
Capacity -- LPH
DISCHARGE PRESSURE
97 SPM
194 SPM
35
151
302
26
50
308
616
13
61
458
916
9
64
505
1010
8
73
657
1314
6
81
808
1616
5
84
870
1740
4.5

Model No. PD - 50
PLUNGER DIA. (MM)
Capacity -- LPH
DISCHARGE PRESSURE
97 SPM
194 SPM
25
128
256
62
35
251
502
32
50
514
1028
15.5
61
765
1530
10.5
70
1007
2014
8
84
1125
2250
7
77
1218
2436
6.5
80
1315
2630
6
86
1520
3040
5
95
1850
3700
4.3
100
2050
4100
4
111
2530
5060
3.2
